Front four-axis thick wire winding machine sp-401c
- Brand: 协普/REPOSAL
- Product Code: sp-401c
- Availability: In Stock
- Ex Tax: 登录以查看价格
Winding machine Features:
This front winding machine ADAPTS the tensioner to the magnetic damping tensioner, and the specific specifications can be selected.
The controller adopts precision CNC winding machine controller and is equipped with Taiwan Dong Yuan inverter to ensure stable operation.
Winding machine professional controller, complete functions, clear hierarchy, simple Settings, additional expansion functions, such as both ends of the deceleration, both ends of the parking, power memory and other functions.
The program can be changed according to the specific requirements of customers to achieve multi-function.
The power supply circuit adopts improved anti-jamming circuit, which has strong anti-jamming ability.
The winding machine wiring system can adjust the position in time during the winding process, and the wiring is stable and low noise.
Can store 1000 groups of processing data, power will not erase, storage call is simple.
Integrated casting case, stable and reliable.
Winding machine Model: sp-401c
Control mode: AC variable frequency motor control
Numb er of spindles: 4 axes
Spindle speed: 5000RPM
Wire diameter range: 0.14-0.5mm
Cable range: 0-120mm
Bag size: 2-25mm
Spindle motor: AC inverter motor 370W
Cable motor: stepping motor
Power supply: single-phase AC220V 50 / 60Hz
Equipment weight: about 48Kg
One-piece cast chassis, with winding and flex cable.
